JET GROUT AND SOIL MIXING EQUIPMENT

Jet grouting is a ground improvement method that can be used for underpinning, water control, earth retention, and other geotechnical challenges. Jet grouting is well-suited for cased complicated by water or requiring targeted treatment.  It is effective across a wide range of soil types, including silts and most clays, making it one of the most versatile techniques. Jet grouting is and erosion-based ground improvement technique that can be used to construct a variety of geometrics, from thin vertical panels, to sector (partial) columns, to full columns of varying diameters. Further, soil-cement properties (i.e. strength, hydraulic conductivity) can be modified by controlling various grouting parameters. Parameters that can be modified include drill rod extraction rate, rotation speed, grout pumping pressures, grout flow, and the specific gravity of the grout. Lastly, the equipment can be sized to accommodate project needs ranging from low-headroom applications to treatment depths over 100 feet deep. This flexibility enables the technique to be tailored to meet the specific project requirements.

Wet soil mixing is the controlled mechanical mixing of the in situ soil with grout slurry using a rotary mixing tool. The wet method relies on the introduction of an engineered grout slurry to create soil-cement (soilcrete) elements for soil stabilization, or to support earth or building loads. The intent of the soil mixing program is to achieve improved engineering properties of the in situ treated soil, generally a design compressive strength, shear strength and/or permeability. Soil mixing can also be used to immobilize and/or stabilize contaminants, or as a chemical treatment system.


TW1020 Compact Jet Unit

TW700 High Pressure
Triplex Pump

TW800 High Pressure
Triplex Pump

State-of-the-art Technology with an Environmental Focus

YBM manufactures a wide range of equipment for use in civil engineering, construction, and mining operations for over 50 years. In addition to providing unsurpassed operating efficiency, our products promote the development of natural resources and energy in an environmentally responsible way.

Depending on the specific topographical and soil conditions, a variety of jet grouting methods may be needed, including single tube, double tube, and triple tube systems. YBM's versatile line of grouting equipment is proven in all of these methods, and is affordable, rugged, and highly efficient.

We place great emphasis on developing advanced technologies that will serve a wide range of user needs and working environments, at affordable pricing levels. Please contact Hennessy International for more information, or visit www.ybm.jp for specifications, photos, description of methods, and additional information.
